TSM156-9-620-645BNDG

浙江双宇电子有限公司

电池技术：	双面, TOPCon
功率范围：	620 ~ 645 Wp
地区：	中国大陆

联系生产商

注意： 您的询盘将直接发送至浙江双宇电子有限公司。

描述：

Excellent anti-LID & anti-PID performance.
Excellent temperature coefficient.
Excellent weak-light performance.
Excellent warranty assurance.

产品信息
公司档案页

产品特点

类型

单晶硅

产品型号

TSM156-9-620BNDG

TSM156-9-625BNDG

TSM156-9-630BNDG

TSM156-9-635BNDG

TSM156-9-640BNDG

TSM156-9-645BNDG

电性能参数（STC）

峰值功率（Pmax）

620 Wp

625 Wp

630 Wp

635 Wp

640 Wp

645 Wp

峰值工作电压（Vmpp）

46.67 V

46.82 V

46.98 V

47.15 V

47.31 V

47.47 V

峰值工作电流（Impp）

13.3 A

13.36 A

13.42 A

13.48 A

13.54 A

13.6 A

开路电压（Voc）

55.82 V

56.01 V

56.2 V

56.4 V

56.6 V

56.79 V

短路电流（Isc）

14.16 A

14.22 A

14.28 A

14.33 A

14.38 A

14.44 A

组件效率

22.2 %

22.4 %

22.5 %

22.7 %

22.9 %

23.1 %

标准测试条件（STC）：太阳能辐射通量1000W/m²，大气参数1.5，组件温度25℃。

电性能参数（NOCT）

峰值功率（Pmax）

469.9 Wp

473.9 Wp

477.6 Wp

481.3 Wp

484.9 Wp

488.9 Wp

峰值工作电压（Vmpp）

43.31 V

43.45 V

43.6 V

43.76 V

43.9 V

44.05 V

峰值工作电流（Impp）

10.85 A

10.91 A

10.95 A

11 A

11.04 A

11.1 A

开路电压（Voc）

51.91 V

52.09 V

52.27 V

52.45 V

52.64 V

52.81 V

短路电流（Isc）

11.61 A

11.66 A

11.71 A

11.75 A

11.79 A

11.84 A

电池片标称工作温度（NOCT）：太阳能辐射通量800W/m²，大气参数1.5，环境温度20℃，风速1 m/s。

物理参数

组件尺寸（高/宽/厚）

2465x1134x30 mm

重量

33.5 kg

PDF

下载公司产品详情

About Us

Zhejiang Twinsel Electronic Technology Co.Ltd. was founded in 2011 and is headquartered in Ninghai County, Zhejiang Province, which is located on the coast of the East China Sea. It is a high-tech, end-use enterprise that integrates research, development, production, and sales.

The company's main businesses include solar lamps and lanterns, LED indoor and outdoor lighting, LED lighting engineering, smart+, photovoltaic modules, portable solar chargers, engineering installations, etc. The products have obtained CCC, CQC, CE, SAA, UL, GS, ROHS, REACH, PAHS, TUV, CSA, Golden Sun, and other domestic and international authoritative quality certificates. The company has ISO9001 quality system certification, ISO14000 environmental system certification, and ISO18000 occupational safety and health management system certification, and has passed the THD, TESCO, AUCHAN, and other major international customers' factory inspection certifications.

Certifications

Exhibition

浙江双宇电子有限公司

: +86 574 59953561
: www.twinsel.com
: 中国大陆
: Tashan Industrial Park, Meilin Street, Ninghai County, Ningbo, Zhejiang

员工数： 2,000

联系生产商

注意： 您的询盘将直接发送至浙江双宇电子有限公司。

晶体硅

产量 (MW)/： MWp

单晶硅，多晶硅，晶体硅

功率范围(Wp)： 100-700

有用联系人

Tony

James Hsu

Mitchell Wu

Nyx Zhang

Jason

Joyce

Jasmine

Betty

Rosy Zhang

Carina Li

Julia

公司描述

Zhejiang Twinsel Electronic Co., Ltd., operating under the brand name Twinsel, is a global provider of smart energy solutions.

Established in 2011 and headquartered in Ningbo, Zhejiang Province, Twinsel is a national-level high-tech company with comprehensive capabilities in research and development, production, and sales. The company primarily focuses on new energy products, particularly PV modules. Twinsel is dedicated to offering a wide range of services to its customers, including consultation, site scouting, design, construction, financing, and smart transportation solutions. Since its inception, the company has expanded its presence internationally, establishing overseas offices in over 10 countries and regions such as the Netherlands, Germany, the United States, India, Bangladesh, Vietnam, and Pakistan. Its business operations span nearly 50 countries and regions worldwide.

Twinsel is committed to creating value for its clients, providing exceptional services, and contributing to their profitability and overall quality of life.
