Mars G3 Series 435-450W

晟高能源科技（江苏）有限公司

价格 / 台
最低订购量	31+ 片
交货时间	7 天
SG-MH60L-435	¥348
SG-MH60L-440	¥352
SG-MH60L-445	¥356
SG-MH60L-450	¥360

电池技术：	背钝化 (PERC)
功率范围：	435 ~ 450 Wp
地区：	中国大陆

联系生产商

注意： 您的询盘将直接发送至晟高能源科技（江苏）有限公司。

描述：

产品信息
公司档案页

产品特点

类型

单晶硅

产品型号

SG-MH60L-435

SG-MH60L-440

SG-MH60L-445

SG-MH60L-450

质量保证

产品质量保证

12 年

功率输出保证

25年期84.8%输出功率保证

电性能参数（STC）

峰值功率（Pmax）

435 Wp

440 Wp

445 Wp

450 Wp

峰值工作电压（Vmpp）

34.23 V

34.39 V

34.46 V

34.62 V

峰值工作电流（Impp）

12.71 A

12.8 A

12.92 A

13.01 A

开路电压（Voc）

40.99 V

41.18 V

41.27 V

41.46 V

短路电流（Isc）

13.32 A

13.37 A

13.42 A

13.47 A

组件效率

20.2 %

20.4 %

20.6 %

20.9 %

标准测试条件（STC）：太阳能辐射通量1000W/m²，大气参数1.5，组件温度25℃。

电性能参数（NOCT）

最大耐久温度

45±2 °C

电池片标称工作温度（NOCT）：太阳能辐射通量800W/m²，大气参数1.5，环境温度20℃，风速1 m/s。

温度特性

工作温度

-40~85 °C

温度系数（Pmax）

-0.35 %/°C

温度系数（Voc）

-0.28 %/°C

温度系数（Isc）

0.045 %/°C

物理参数

组件尺寸（高/宽/厚）

1903x1134x35 mm

重量

24 kg

电池片规格

182×182 mm

电池片数量

120

玻璃类型

防反射镀膜，钢化

玻璃厚度

3.2 mm

边框类型

阳极氧化铝

接线盒防护等级

IP 68

连接器类型

MC4

电缆截面

4 mm²

电缆长度

300 mm

PDF

下载公司产品详情

Mars G3 Series 435-450W

SUNGO, a global leading innovative solar module manufacturer, is committed to providing customers with high-performance and advanced solar products.

SUNGO redefines a variety of high efficiency PERC Mono Solar Modules by integrating large silicon wafers with half-cut /trisection-cut cell, multi-busbar, bifacial-cell, dual-glass, high-density encapsulation and other related technologies.

Product Features:

● New circuit design with half-cut cell technology decreases internal current & resistances loss

● High-efficiency PERC cells for improved performance

● 100% triple EL test to reduce hidden crack rate of modules

● Special design with lower hot spot temperature minimizes risk of hot spots

● Bigger size 182mm M10 cells deliver high power generation with lower LCOE

● 12 years product warranty & guaranteed power output of 84.8% after 25 years
