A-265-280P GSE (BS)

A-265-280P GSE (BS)

Atersa
电 池 技 术:
功率范围: 265 ~ 280 Wp
地区: 西班牙 西班牙
联系生产商
注意: 您的询盘将直接发送至Atersa

替代产品

HT Series TOPC...

弘元光能(无锡)有限公司
起价 ¥1.02 / Wp *
  • 电 池 技 术: 双面,TOPCon
  • 组件尺寸: 2382x1134x30 mm
  • 重量: 33.7 kg
  • 电池片规格: --
  • 玻璃厚度: 2 mm

产品特点

类型 多晶硅
产品型号
A-265P GSE A-270P GSE A-275P GSE A-280P GSE
质量保证
产品质量保证 10 年
功率输出保证 25年期80%输出功率保证
电性能参数(STC)
峰值功率 (Pmax)
265 Wp 270 Wp 275 Wp 280 Wp
峰值工作电压(Vmpp)
30.4 V 30.6 V 30.8 V 31 V
峰值工作电流(Impp)
8.39 A 8.5 A 8.61 A 8.71 A
开路电压(Voc)
37.7 V 37.9 V 38.1 V 38.3 V
短路电流(Isc)
8.88 A 8.98 A 9.07 A 9.16 A
组件效率
15.7 % 16 % 16.3 % 16.6 %
功率偏差(正)
+ 2 % + 2 % + 2 % + 2 %
  标准测试条件(STC):太阳能辐射通量1000W/m2,大气参数1.5,组件温度25℃。
电性能参数(NOCT)
最大耐久温度 45±2 °C
  电池片标称工作温度(NOCT):太阳能辐射通量800W/m2,大气参数1.5,环境温度20℃,风速1 m/s。
温度特性
工作温度 -40~85 °C
温度系数(Pmax) -0.43 %/°C
温度系数(Voc) -0.33 %/°C
温度系数(Isc) 0.05 %/°C
系统集成参数
最大系统电压 1000 V
保险丝额定电流 15 A
物理参数
组件尺寸(高/宽/厚) 1640x992x40 mm
重量 18.5 kg
电池片规格 156×156 mm
电池片数量 60
玻璃类型 钢化
玻璃厚度 3.2 mm
边框类型 阳极氧化铝
旁路二极管数 3
接线盒防护等级 IP 67
连接器类型 MC4
电缆截面 4 mm2
电缆长度 1100 mm

Atersa

Click to show company phone
https://www.atersa.com
西班牙
Princesa 25, 2ª planta, 28008 Madrid
母公司: Elecnor
注意: 您的询盘将直接发送至Atersa

晶体硅

产量 (MW)/: MWp
单晶硅,多晶硅
功 率 范 围(Wp): 10-550

评价

Modules of high efficiency. Immediate service and highly competitive value for the money. This company also has other kind of products valid for small installers: off grid PV modules, charge controllers, batteries, ... Furthermore, their modules are covered by warranty for 10 years.

-- Cero Grados Sur, S.L.

For installations in which we have used these panels the results have been satisfactory, resulting in a higher than expected performance.

-- Quetzal Ingeniería

We have been working with these panels for ten years so we have a very good relationship with this manufacturer and we trust their products.

-- Igoan Solar S.L.

The best quality of these panels is its price. To be priced lower than other brands makes them an option to be considered in your installations. Their overall performance and quality are also good so these panels are a good value for your money.

-- Fernando Garcia Alcaraz, Clima Sonair, S.L
