  1. 光伏逆变器产品名录
  2. Mars-5/6/8/10/12/14G1-LE
Mars-5/6/8/10/12/14G1-LE
Mars-5/6/8/10/12/14G1-LE
Mars-5/6/8/10/12/14G1-LE

Mars-5/6/8/10/12/14G1-LE

浙江中哲新能源科技有限公司
价 格：
起价 ¥0.891 / Wp *
起价 ¥11,700 / 台 *
类型： 混合
功率范围： 6~15.4 kW
地区： 中国大陆 中国大陆
联系生产商
注意： 您的询盘将直接发送至浙江中哲新能源科技有限公司。

描述：

100% unbalanced output, each phase max. output up to 50% rated power

Support on/off-grid mode switch, EPS output

Colorful 7-inch touch LCD, IP65 protection degree

Support battery charging/discharging according to the time setting

Independent AC input port for diesel generator

Support storing energy from diesel generator

ARC fault detection optional

产品特点

产品型号
Mars-5G1-LE Mars-6G1-LE Mars-8G1-LE Mars-10G1-LE Mars-12G1-LE Mars-14G1-LE
产品规格
功率
6 kW 7.2 kW 9.6 kW 12 kW 13.2 kW 15.4 kW
价格
¥11,700 / 台 * ¥12,100 / 台 * ¥12,500 / 台 * ¥12,800 / 台 * ¥13,300 / 台 * ¥13,700 / 台 *
质量保证
产品质量保证 （最低）
5 年 5 年 5 年 5 年 5 年 5 年
输入参数（直流）
最大输入功率
7.5 kW 9 kW 12 kW 15 kW 18 kW 20 kW
最大输入电压
650 V 650 V 650 V 650 V 650 V 650 V
最小输入电压
160 V 160 V 160 V 160 V 160 V 160 V
最大输入电流
40 A 40 A 40 A 54 A 54 A 54 A
MPP(T)电压范围
200~700 V 200~700 V 200~700 V 200~700 V 200~700 V 200~700 V
MPPT数量
2 2 2 2 2 2
直流输入连接端数
2 2 2 3 3 3
输出参数（交流）
最大输出功率
6 kW 7.2 kW 9.6 kW 12 kW 13.2 kW 15.4 kW
标称交流电压
380, 400 V 380, 400 V 380, 400 V 380, 400 V 380, 400 V 380, 400 V
最大输出电流
11.4 A 13.6 A 18.2 A 22.7 A 27.3 A 27.6 A
频率
50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz
总谐波失真 （THDi）
< 3 % < 3 % < 3 % < 3 % < 3 % < 3 %
相数
3 3 3 3 3 3
最大效率
97.9 % 97.9 % 97.9 % 97.9 % 97.9 % 97.9 %
欧洲效率
96.9 % 96.9 % 96.9 % 96.9 % 96.9 % 96.9 %
一般参数
尺寸（高/宽/厚）
630x510x290 mm 630x510x290 mm 630x510x290 mm 630x510x290 mm 630x510x290 mm 630x510x290 mm
重量
38 kg 40 kg 42 kg 44 kg 44 kg 45 kg
噪音干扰级别
< 45 dB(A) < 45 dB(A) < 45 dB(A) < 45 dB(A) < 45 dB(A) < 45 dB(A)
工作温度范围 -40 ~ +60 ℃
防护等级 IP65
散热方式 风扇冷却
通讯接口 RS 485
显示屏 LCD
防护性能
防护性能 反孤岛保护（ENS），短路保护，过流保护，漏电保护设备（RCD），极性反接保护
PDF
下载公司产品详情

Chisage Mars series IP65 triple-phase hybrid inverter has a simple and elegant appearance with a 7-inch LCD that will fit perfectly into your home environment.

It has the ON/OFF GRID mode switching function and supports Max.20 pcs in parallel for off-grid. It also supports triple-phase mode and full-power single-phase mode and also supports storing energy from the diesel generator. The ARC fault detection optional function and the function of charging/discharging the battery according to the time setting can make the operation more convenient.

Company Introduction

Our main products for battery packs include the low voltage 51.2V/100Ah and 200Ah lithium battery packs and high voltage 115.2V/72Ah and 100Ah lithium battery packs. About the hybrid inverters, we have 3kW-20kW on and off-grid hybrid and 3kW -10kW off-grid for households, and 30kW-150kW hybrid inverters for commercial and industrial applications, which can be connected with solar +battery+ DG. We also have the all-in-one hybrid generator with 5kW/10kWh,10kWh/20kWh for households, and 100kW/200kWh, 250kW/500kWh solar+ESS hybrid all-in-one cabinets for commercial and industrial applications.

We manufacture with innovation and reliability. We are dedicated to delivering the customers our best solutions.

浙江中哲新能源科技有限公司

+86 1505 7491 826
www.chisagess.com
中国大陆
No. 1828, Fuqing South Rd, Yinzhou District, Ningbo, Zhejiang, 31500
员工数： 500
母公司： Chisage Holding Group Co., Ltd.
联系生产商
注意： 您的询盘将直接发送至浙江中哲新能源科技有限公司。

有用联系人

公司描述

Chisage ESS is the holding subsidiary of Chisage Group, founded in 1998. After more than two decades of growth, it has 358 employees, including 53 experienced R&D staff, 20 overseas engineers, 32 technical support staff, and 15 after-sales service staff.

With 6 high-tech production lines, its annual output is over 50,000 pcs. Chisago ESS also has branch offices and showrooms in 6 countries including Germany, South Africa, Lebanon, Pakistan, Italy, and Hungary.
